Victron Energy Three-Phase Energy Meter EM340 (REL300300000) — is the newest, ultra-fast energy meter from Carlo Gavazzi, specially adapted to work with Victron Energy equipment. It measures the parameters of a three-phase AC network and transmits data to the GX panel (Cerbo GX, Ekrano GX) via the RS-485 interface. The main difference of the EM340 model is the incredibly high data update rate (every 100 ms), which makes the reaction of the ESS system to load changes almost instantaneous.
Features and Advantages of the EM340 Meter
- Ultra-fast polling (100 ms): allows MultiPlus inverters to instantly compensate for consumption, minimizing accidental energy discharge into the grid.
- High power: direct load connection up to 65 A per phase.
- Easy setup: does not require additional configuration via the UCS program, as was the case with previous models (EM24).
- Informative display: bright LCD screen for direct reading of voltage, current, active, and reactive power.
Technical Specifications
- Article: REL300300000 (check model compatibility)
- Number of phases: 3 phases / 4 wires
- Maximum current: 65 A per phase (direct connection)
- Communication interface: RS-485
- Nominal voltage: 230 V / 400 V (AC)
- Mounting: on DIN rail (3 modules)
- Measured parameters: V, A, W, Hz, kWh (import/export)
Applications
- Three-phase hybrid Energy Storage Systems (ESS), where the maximum compensation speed is important (no "dips" and "surges" in the utility company's meter).
- Managing complex solar power plants with the Zero Feed-in function.
- Monitoring powerful grid-tied solar inverters via the VRM portal.
Integration with Victron Equipment
To connect the EM540 meter to GX control panels, the original Victron RS485-USB interface cable is required. Due to its high polling rate, this meter is the preferred choice for new ESS installations.
